Agricultural Tractor Rear Tyres

We manufacture, export and supply durable Agricultural Tractor Rear Tyres. The company is the responsive and responsible Manufacturer, Exporter & Supplier of Agricultural Tractor Rear Tyres in Punjab, India.

Geestone 81

Size	Pattern	Ply Rating	Rim Width	Inflated Dimensions +/-2%		Load Capacity (Kg)	I.P (Bar)
Size	Pattern	Ply Rating	Rim Width	OD (mm)	CSW (mm)	Load Capacity (Kg)	I.P (Bar)
11.2-24	81	8PR	10	1105	284	1250	2.4
12.4-24	81	8PR	11	1160	315	1450	2.3
12.4-28	81	12PR	11	1260	315	1650	2.5
13.6-28	81	12PR	12	1310	345	1800	2.3
14.9-26	81	8PR	13	1295	378	1750	1.6
14.9-24	81	8PR	13	1265	378	1800	1.8
14.9-28	81	8PR	13	1365	378	1900	1.8
18.4-26	81	12PR	16	1450	467	3000	2.3
16.9-34	81	10PR	15	1585	429	2650	2.0
18.4-34	81	10PR	16	1654	467	2650	1.40
18.4-38	81	8PR	W16	1760	467	2725	1.40
8.00-18	81	4PR	W7	835	206	515	1.60
8.3-20	81	6PR	W7	890	211	710	2.40
16.0/70-20	81	14PR	14	1097	418	Free Rolling 3750 Drive Wheel 2650	3.50

Geestone 82

Size	Pattern	Ply Rating	Rim Width	Inflated Dimensions +/-2%		Load Capacity (Kg)	I.P (Bar)
Size	Pattern	Ply Rating	Rim Width	OD (mm)	CSW (mm)	Load Capacity (Kg)	I.P (Bar)
12.4-28	82	12PR	11.00	1260	315	1650	2.50
11.2-28	82	6PR	10.00	1205	284	1120	1.80
8.3-24	82	6PR	W7	995	211	825	2.40
9.5-24	82	8PR	W8	1050	241	1120	2.80

Geestone 83

Size	Pattern	Ply Rating	Rim Width	Inflated Dimensions +/-2%		Load Capacity (Kg)	I.P (Bar)
Size	Pattern	Ply Rating	Rim Width	OD (mm)	CSW (mm)	Load Capacity (Kg)	I.P (Bar)
12.4-28	83	12PR	11.00	1260	315	1650	2.50
16.9-28	83	12PR	15.00	1435	429	2725	2.60
16.9-30	83	12PR	15.00	1485	429	2800	2.40
18.4-30	83	12PR	16.00	1550	467	3250	2.30

Geestone 84

Size	Pattern	Ply Rating	Rim Width	Inflated Dimensions +/-2%		Load Capacity (Kg)	I.P (Bar)
Size	Pattern	Ply Rating	Rim Width	OD (mm)	CSW (mm)	Load Capacity (Kg)	I.P (Bar)
16.9-28	84	12PR	15.00	1410	429	3550	2.6

Geestone 85

Size	Pattern	Ply Rating	Rim Width	Inflated Dimensions +/-2%		Load Capacity (Kg)	I.P (Bar)
Size	Pattern	Ply Rating	Rim Width	OD (mm)	CSW (mm)	Load Capacity (Kg)	I.P (Bar)
15.5/80-24	85	14PR	13	1262	394	Free Rolling 4500 Drive Wheel 3150	350

Geestone 86

Size	Pattern	Ply Rating	Rim Width	Inflated Dimensions +/-2%		Load Capacity (Kg)	I.P (Bar)
Size	Pattern	Ply Rating	Rim Width	OD (mm)	CSW (mm)	Load Capacity (Kg)	I.P (Bar)
16.0/70-20	86 (HW-80)	14PR	14	1097	418	Free Rolling 3750 Drive Wheel 2650	3.50
